LLT M19 push lock female front panel mount waterproof connector
LLT M19 push lock female front panel mount waterproof connector - Image 2
LLT M19 push lock female front panel mount waterproof connector - Image 3
LLT M19 push lock female front panel mount waterproof connector - Image 4
LLT M19 push lock female front panel mount waterproof connector - Image 5

LLT M19 push lock female front panel mount waterproof connector

M19 Parametric Table

Cores Voltage Current Wire Gauge
2P 250V 20A ≤2.5mm²
3P 250V 20A ≤2.5mm²
4P 250V 20A ≤1.5mm²
5P 250V 15A ≤1.0mm²
6P 250V 15A ≤0.75mm²
7P 100V 5A ≤0.75mm²
8P 100V 5A ≤0.5mm²
9P 100V 5A ≤0.3mm²
10P 100V 5A ≤0.3mm²
12P 100V 5A ≤0.2mm²
14P 100V 5A ≤0.2mm²
18P 100V 5A ≤0.2mm²

Specs: IP67 | 3000 Cycles | -40℃~+105℃ | Cable: 6-10mm

*Prices per set, shipping not included

Category:
M19 push lock front panel mount connector design

M19 Push Lock Front Panel Mount Connectors

Professional Electrical Connector Selection: conn-llt.cn/selector.html

M19 Push Lock · Advanced Electrical Connector Design

M19 push lock front panel layout electrical connector design

Precision Push Lock Connection

Our M19 push lock front panel mount connector design utilizes a spring-loaded cam mechanism engineered for optimal electrical contact force distribution. The internal spring assembly maintains consistent contact pressure while the cam profile geometry ensures secure mechanical retention. This electrical connector design has undergone 7 major design iterations with extensive field testing across horticultural and industrial applications.

⚡ Single-action connection with tactile feedback confirmation
🔒 Mechanical lock prevents vibration loosening, IP68 rated
🎯 Market-proven reliability through iterative optimization

Comprehensive Pin Configuration Options

M19 connector pin configuration mating system

Mating System Design

Precision-engineered pin-to-socket alignment for reliable electrical connectivity

M19 push lock connector assembly configuration

Complete Assembly System

Front panel mount with integrated push lock mechanism

Extensive Pin Configuration Matrix

2-19
Pin Options
Power & Signal
40A
Max Current
Per Contact
IP68
Protection
Waterproof Rated
1000V
Max Voltage
AC/DC Rating

The M19 connector series offers unparalleled versatility with configurations from 2-pin to 19-pin arrangements, making it the industry standard for full-spectrum horticultural lighting and precision industrial applications.

Full-Spectrum Horticultural Applications

M19 electrical connector for horticultural LED systems
Full-Spectrum LED Arrays
M19 connector design for plant growth lighting systems
Advanced Growth Chambers
M19 push lock connector for LED strip control systems
Precision Control Systems
M19 electrical connector for greenhouse automation
Greenhouse Automation

Connector Design Innovation

Spring Mechanism Engineering

Precision-wound stainless steel springs provide consistent 15-20N engagement force, ensuring reliable electrical contact while maintaining smooth operation through 10,000+ mating cycles.

Contact Geometry Optimization

Gold-plated copper alloy contacts with optimized wiping action eliminate oxidation and ensure low-resistance connections under high-current applications.

Housing Material Science

UV-stabilized PA66 polymer with 30% glass fiber reinforcement provides exceptional dimensional stability and chemical resistance in harsh environments.

LLT Connectors™ - Engineering Excellence

Industry-Leading Connector Design

🏭
Production Scale: 162,000m² advanced manufacturing facilities
⚙️
M19 Capacity: 5M+ electrical connectors monthly output
📜
Innovation Portfolio: 200+ connector design patents
LLT precision electrical connector manufacturing facility

Automated Precision Manufacturing

Market-Proven Electrical Connector Solutions

Horticultural Lighting
60%+ market share in full-spectrum applications
Industrial Automation
Trusted by Fortune 500 manufacturers
Electric Vehicle Systems
High-voltage platform integration
Renewable Energy
Solar and wind power applications
